Seamless St 52 BK+S pipes, 5-stage telescopic cylinder, oil tank with No.46 hydraulic oil, electrically controlled valve in a limited closed-circuit hydraulic system.
Axles
Axles certified at R13.11 Regulation level, equipped with domestic drum brakes; each axle group has a capacity of 3×12 tons, with a liftable front axle.
Bucket
Body compliant with Directive 1230/2012, reinforced with high-strength steel profiles. Floor: 3 mm Hardox 450 Sides: 3 mm Hardox 450 Reinforcement profiles: 4 mm Rear door: 3 mm Hardox 450, 1900 mm height, mechanical, double-acting.
Surface Protection
SA 2½ sandblasting, epoxy primer and topcoat in requested RAL color (approx. 120 microns).
King Pin
2” king pin compliant with ECE R55.01.
RU:
Brake System
Compliant with R13 Regulation; equipped with RSS stability control, 2S-2M sensor system. 1st axle: 30 service brake chamber 2nd & 3rd axles: 30×30 spring brake chambers Automatic slack adjuster; R10 electromagnetic compatibility.
Air suspension supported by leaf and air bags, with shock absorbers preventing excessive axle movement.
Electrical System
R48 regülasyon seviyesinde 2×7 pin soket, 24 volt aydınlatma, yan lambalar, stop lambası, plaka lambası, geri vites lambası , uygun reflektif şerit 103/2010 direktifine uygun tescil plaka yeri
Tires + Rims
6 units of 385/65 R 22.5 tires and 11.75×22.5 rims compliant with 92/23/EEC*2005/11/EC standards.
Chassis
Flexible and durable I-profile chassis made from S700 quality steel plates, strengthened through cutting and bending, and assembled using MAG/submerged arc welding.
Accessories
Steel toolbox, 35 L water tank, fire extinguisher cabinet, reflector, spare wheel holder, wheel chock and holder, axle hub cap wrench, R58 rear underrun protection, R73 side guards, mud-flaps per 109/2011.
